Types of Jib Cranes
The trolley hoist on a horizontal load-bearing boom are key features on Jib cranes. The boom is secured to a vertical mast which measures up to 20 feet long. Jib cranes are able to move loads between any areas within the boom's arc of rotation. Light duty units are utilized in warehouses and factories for loads weighing as much as 5 tons. The web site BestJibCranes.com showcases the major kinds of jib cranes as being either mast mounted, free-standing or wall-mounted.
Free Standing
The free-standing jib crane models do not require any support from the building structure and can stand by themselves. The horizontal boom in this particular case is attached to a pivoting vertical column which is firmly anchored to the building floor. This type of jib crane can rotate a full 360 degrees and requires a foundation made of either concrete or steel.
Mast-Type
The mast-type jib cranes feature a vertical column that is supported by pivot points at the bottom and the top which are connected to the building floor and the overhead steel structure. These jib-cranes provide 360 degrees of rotation with the benefit of not needing the massive foundation required for free-standing units.
Wall Mounted
Wall mounted jib cranes are attached to the wall of the building rather than supporting a normal vertical column. These cranes offer a horizontal boom. These equipments provide up to 200 degrees of rotation and are ideal in places where the full 360 degree rotation is not required.
Depending on how the boom is supported, there are two model varieties. One type utilizes a tie rod from above the boom that is connected to the wall. The other kind supports the boom from below by using a cantilever brace which is connected to the wall too.
